Wrapper class for dealing with data from matlab. More...

#include <wrapper_i_matlab.h>

Inheritance diagram for utilities::Wrapper_i_matlab:

Collaboration diagram for utilities::Wrapper_i_matlab:

Public Member Functions
bool	contains_type (D_TYPE type) const
	Returns if the wrapper contains the specified data type.
std::set< utilities::D_TYPE >	get_data_types () const
	Returns a set of the data types.
void	get_data_types (std::set< utilities::D_TYPE > &) const
Tuplef	get_dims () const
	Returns the dimension of each 'frame' of the data in the wrapper.
int	get_num_entries () const
	Return the total number of entries in the wrapper.
int	get_num_entries (unsigned int frame) const
	Return the number of entries the specified frame.
int	get_num_frames () const
	Return the number of frames.
int	get_value (int &out, int ind, D_TYPE type, int frame) const
	Returns the value of the type specified from the particle selected.
float	get_value (float &out, int ind, D_TYPE type, int frame) const
	Returns the value of the type specified from the particle selected.
std::complex< float >	get_value (std::complex< float > &out, int ind, D_TYPE type, int frame) const
	Returns the value of the type specified from the particle selected.
void	print () const
	Wrapper_i_matlab (const mxArray **mex_array, std::map< utilities::D_TYPE, int > contents, Tuplef dims)
	~Wrapper_i_matlab ()
Meta data handling functions
const Md_store *	get_Md_store (unsigned int j) const
	Returns a pointer to plane j's meta data store.
Md_store *	get_Md_store (unsigned int j)
	Returns a pointer to plane j's meta data store.
void	set_Md_store (unsigned int j, Md_store *in)
	Sets the Md_store for plane j.
void	set_Md_store_size (unsigned int j)
	Sets the size of the md_stores_ vector.
unsigned int	get_Md_store_size ()
	Gets the size of the md_stores_ vector.
void	clear_Md_store (unsigned int j)
	Deletes plane j's Md_store.
Private Member Functions
float	get_value (int ind, utilities::D_TYPE type, int junk) const
	internal get_value
void	init ()
	internal initialization
Private Attributes
int	cols_
	The number of columns (and hence number of values in the array.
Data_map	data_map_
	object for fast lookup
std::map< utilities::D_TYPE, int >	data_types_
	A map between the data types and a posistion in the data structure.
Tuplef	dims_
	Dimensions.
const double *	first_
	anchor to data with in array
std::vector< unsigned int >	frame_offsets_
	Offsets of which row each set of frames starts on.
int	frames_
	The number of frames in the wrapper.
const mxArray **	mex_array_
	Pointer to matlab array that holds the data.
int	rows_
	The number of rows in the array.

Detailed Description

Wrapper class for dealing with data from matlab.

Constructor & Destructor Documentation

Wrapper_i_matlab::~Wrapper_i_matlab ( )

References first_.

Wrapper_i_matlab::Wrapper_i_matlab	(	const mxArray **	mex_array,
		std::map< utilities::D_TYPE, int >	contents,
		Tuplef	dims
	)

References utilities::D_FRAME, data_map_, utilities::DT2str_s(), first_, frame_offsets_, frames_, and rows_.

Member Function Documentation

void Wrapper_in::clear_Md_store ( unsigned int j ) [inherited]

Deletes plane j's Md_store.

References utilities::Wrapper_in::md_stores_.

bool Wrapper_i_matlab::contains_type ( D_TYPE type ) const [virtual]

Returns if the wrapper contains the specified data type.

Implements utilities::Wrapper_in.

References data_types_.

std::set< utilities::D_TYPE > Wrapper_i_matlab::get_data_types ( ) const [virtual]

Returns a set of the data types.

Use the other version

Implements utilities::Wrapper_in.

References data_types_.

Referenced by get_data_types().

void Wrapper_i_matlab::get_data_types ( std::set< utilities::D_TYPE > & out ) const

References get_data_types().

Tuplef Wrapper_i_matlab::get_dims ( ) const [virtual]

Returns the dimension of each 'frame' of the data in the wrapper.

Implements utilities::Wrapper_in.

References dims_.

const Md_store * Wrapper_in::get_Md_store ( unsigned int j ) const [inherited]

Returns a pointer to plane j's meta data store.

Const version

References utilities::Wrapper_in::md_stores_.

Referenced by tracking::Master_box::get_Md_store(), and tracking::hash_case::init().

Md_store * Wrapper_in::get_Md_store ( unsigned int j ) [inherited]

Returns a pointer to plane j's meta data store.

Const version

References utilities::Wrapper_in::md_stores_.

unsigned int Wrapper_in::get_Md_store_size ( ) [inherited]

Gets the size of the md_stores_ vector.

References utilities::Wrapper_in::md_stores_.

int Wrapper_i_matlab::get_num_entries ( ) const [virtual]

Return the total number of entries in the wrapper.

Implements utilities::Wrapper_in.

References rows_.

int Wrapper_i_matlab::get_num_entries ( unsigned int frame ) const [virtual]

Return the number of entries the specified frame.

Implements utilities::Wrapper_in.

References frame_offsets_.

int Wrapper_i_matlab::get_num_frames ( ) const [virtual]

Return the number of frames.

Implements utilities::Wrapper_in.

References frames_.

float Wrapper_i_matlab::get_value	(	int	ind,
		utilities::D_TYPE	type,
		int	junk
	)		const `[private]`

internal get_value

References data_map_, utilities::DT2str_s(), first_, frame_offsets_, and rows_.

Referenced by get_value().

int Wrapper_i_matlab::get_value	(	int &	out,
		int	ind,
		D_TYPE	type,
		int	frame
	)		const `[virtual]`

Returns the value of the type specified from the particle selected.

Parameters:

out	[out] the value
ind	[in] the index of the particle
type	[in] the D_TYPE
frame	[in] the frame the particle is in

Returns:: the value

Implements utilities::Wrapper_in.

References get_value().

float Wrapper_i_matlab::get_value	(	float &	out,
		int	ind,
		D_TYPE	type,
		int	frame
	)		const `[virtual]`

Returns the value of the type specified from the particle selected.

Parameters:

out	[out] the value
ind	[in] the index of the particle
type	[in] the D_TYPE
frame	[in] the frame the particle is in

Returns:: the value

Implements utilities::Wrapper_in.

References get_value().

complex< float > Wrapper_i_matlab::get_value	(	std::complex< float > &	out,
		int	ind,
		D_TYPE	type,
		int	frame
	)		const `[virtual]`

Returns the value of the type specified from the particle selected.

Parameters:

out	[out] the value
ind	[in] the index of the particle
type	[in] the D_TYPE
frame	[in] the frame the particle is in

Returns:: the value

Implements utilities::Wrapper_in.

void utilities::Wrapper_i_matlab::init ( ) [private]

internal initialization

void Wrapper_i_matlab::print ( ) const

References cols_, and rows_.

void Wrapper_in::set_Md_store	(	unsigned int	j,
		Md_store *	in
	)		`[inherited]`

Sets the Md_store for plane j.

When the pointer is assigned the wrapper takes ownership of the pointer and will clean it up.

References utilities::Wrapper_in::md_stores_.

Referenced by iden::Iden::fill_wrapper(), iden::Iden::fill_wrapper_avg(), main(), and utilities::Wrapper_i_hdf::priv_init().

void Wrapper_in::set_Md_store_size ( unsigned int j ) [inherited]

Sets the size of the md_stores_ vector.

References utilities::Wrapper_in::md_stores_.

Referenced by iden::Iden::fill_wrapper(), iden::Iden::fill_wrapper_avg(), main(), and utilities::Wrapper_i_hdf::priv_init().

Member Data Documentation

int utilities::Wrapper_i_matlab::cols_ [private]

The number of columns (and hence number of values in the array.

This isn't strictly needed, hoever it should make returning values faster by amoritizing the dereference cost, maybe

Referenced by print().

Data_map utilities::Wrapper_i_matlab::data_map_ [private]

object for fast lookup

Referenced by get_value(), and Wrapper_i_matlab().

std::map<utilities::D_TYPE, int> utilities::Wrapper_i_matlab::data_types_ [private]

A map between the data types and a posistion in the data structure.

This orginally had been burried down in the derived classes, but I couldn't think of a data structure for storing particle data where this sort of thing wasn't uesful. Thus, it has been dragged up to the top level.

Referenced by contains_type(), and get_data_types().

Tuplef utilities::Wrapper_i_matlab::dims_ [private]

Dimensions.

Referenced by get_dims().

const double* utilities::Wrapper_i_matlab::first_ [private]

anchor to data with in array

Referenced by get_value(), Wrapper_i_matlab(), and ~Wrapper_i_matlab().

std::vector<unsigned int> utilities::Wrapper_i_matlab::frame_offsets_ [private]

Offsets of which row each set of frames starts on.

This is needed because of the way that locations are stored in matlab vs how they are stored in hdf files.

Referenced by get_num_entries(), get_value(), and Wrapper_i_matlab().

int utilities::Wrapper_i_matlab::frames_ [private]
